Analysis of common faults in Wire Harness processing

The law of Wire Harness burnout is as follows: In the power system circuit, where to take the iron, Wire Harness to burn where, burned and intact parts of the junction, can be considered to be Wire Harness to take the iron, such as Wire Harness burned bad to the wiring position of an electrical equipment, indicating that the electrical equipment failure.

1. The battery line is burnt out

If only part of the battery line is burned out, check the parts in contact with the cable burned out, clean the burr and replace the battery line. If all the battery wires are burnt out, the starter is out of order. A test light is connected to the positive pole of the starter electromagnetic switch and the positive pole of the battery. If the test light is on, it indicates that the electromagnetic switching fails; If the test light is not on, it indicates that there is a fault inside the starter.

2. The Wire Harness between the positive terminal of the generator and the terminal of the starter battery is burned out

Stop the generator, remove the lead of the positive pole of the motor, connect a power cord between the battery + pole, and the other end is in contact with the positive pole of the generator. If there is a spark, it indicates that the generator is faulty. If there is no spark, it indicates that the Wire Harness is faulty.

3. Wire Harness and relay lead burned out

Turn off the power switch, remove the relay and let it hang in the air. Connect a test light between the relay shell and the body. If the light is on, it indicates that the relay is faulty; If the light is not on, perform the following steps. Turn on the power switch. If the test light is not on, it indicates that the relay is not faulty and only replace the Wire Harness. If the test light indicates that the relay is faulty, replace the relay.
